Instrumentation Manifolds
| Part Number | Material | Category | Description | Image |
|---|---|---|---|---|
| 2R6L-FNS8-V | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2R6L-FNS8-V-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting, FC-02 Cleaned | IMAGE |
| 2R6L-FNS8-V-P | 316L SS | 2-Valve Manifold | Body:316L SS, MWP:6,000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Remote Mounting，with plug | IMAGE |
| 2R6L-FNS8-V-S | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR 0175 | IMAGE |
| 2R6L-FNS8-V-T | 316L SS | 2-valve Manifolds | Body:316LSS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:Block-Needle, Vent-Needle, Remote Mounting，RB relief valve | IMAGE |
| 2RD7-FNS8-V | Super Duplex | 2-valve Manifolds | Body:Super Duplex S32750, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2RHD7-FNS8-V | Super Duplex | 2-valve Manifolds | Duplex2507, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(649bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted. | IMAGE |
| 2RHSS-FNS8-V | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(649bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 2RHSS-FNS8-V-P | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(649bar), -65°F to 450°F(-54°C to 232°C),with plug | IMAGE |
| 2RHSS-FNS8-V-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, In&Out: 1/2 Female NPT, Vent: 1/4 Female NPT with Plug, NACE MR0175 | IMAGE |
| 2RHSS-FNS8-V-S | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(649bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted,NACE MR 0175 | IMAGE |
| 2RHSS-FNS8-V-SF2 | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(649bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted, NACE MR0175, F2 | IMAGE |
| 2RS1-FNS8-V | 321 SS | 2-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2RSS-FNS8-V | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 2RSS-FNS8-V-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, FC-02 Cleaned | IMAGE |
| 2RSS-FNS8-V-G | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphtie, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35 Al T-bar Handles. | IMAGE |
| 2RSS-FNS8-V-G-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphtie, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35 Al T-bar Handles. | IMAGE |
| 2RSS-FNS8-V-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted, Test Port with Plug | IMAGE |
| 3D6L-FNS4-V-M | 316L SS | 3-valve Manifolds | 316L SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DD7-FNS8-V-P | Super Duplex | 3-valve Manifolds | 3D Series Direct Mount 3-valve Manifold, Duplex 2507 Body, Max. Working Pressure: 6, 000psig, Inlet/Process: 1/2’’ Female NPT, Outlet/Instrument: Flange, Test: 1/4’’ Female NPT with Plug, PTFE Packing | IMAGE |
| 3DS1-FNS8-V-S | 321 SS | 3-valve Manifolds | 3D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange. | IMAGE |
| 3DSS-FNS8-V | 316 SS | 3-valve Manifolds | Body:316SS, MWP:6,000psig, Packing :PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flanged (54mm), Vent:No, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate & 1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-V-M | 316 SS | 3-valve Manifolds | 316 SS 3 way manifolds, direct mount, 1/2" female NPT inlet, flange outlet, valves vertically mouted,316 SS bolt. | IMAGE |
| 3DSS-FNS8-V-M-S | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flanged (54mm), Vent:No, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-V-P | 316 SS | 3-valve Manifolds | 3D Series Direct Mount 3-valve Manifold,316 SS Body, Max. Working Pressure: 6, 000psig, Inlet/Process: 1/2’’ Female NPT, Outlet/Instrument: Flange, Test: 1/4’’ Female NPT with Plug, PTFE Packing | IMAGE |
| 3DSS-FNS8-V-P-M | 316 SS | 3-valve Manifolds | maximum working pressure 6000psi, -54 ℃ to 232 ℃; The inlet is 1/2 "NPTF,the outlet is flange, and the center distance of the outlet flange is 54mm; the valve is installed vertically | IMAGE |
| 3DSS-FNS8-V-P-MFB | 316 SS | 3-valve Manifolds | 316 SS,3D Series 3-valve Manifold, Inlet/Process: 1/2" Female NPT, Outlet/Instrument: Flange, with Plug, as per drawing | IMAGE |
| 5D6L-FNS8-V-M | 316L SS | 5-valve Manifolds | Five valves in one plane, with a MWP: of 6000psi, working temperature: -54℃ to 232℃,Inlet 1/2"NPT female thread, outlet flange, valve installed vertically,Bolts 7/16-20UNF*1.75", made of stainless steel. | IMAGE |
| 5DSS-FNS8-VB | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with traditional flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Vertically Mounted, Double-equalize | IMAGE |
| 5DSS-FNS8-VB-E-M-ME | 316 SS | 5-valve Manifolds | five valve manifold,MWP:6000PSI,working temperature: - 54 ℃ to 232 ℃;The inlet is 1/2"NPT female thread,the outlet is flange,and the valve is installed vertically;The bolt is 7/16-20unf * 1.75 ",made of stainless steel.See the drawing for details | IMAGE |
| 5DSS-FNS8-V-M | 316 SS | 5-valve Manifolds | 5D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20×1.75" bolt, Bolt 316 SS. | IMAGE |
| 5DSS-FNS8-V-P | 316 SS | 5-valve Manifolds | 5D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20×1.75" bolt, Bolt 316 SS, 1/4" Female NPT with Plug | IMAGE |
| 3D6L-FNS8-A | 316L SS | 3-valve Manifolds | 316L SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3D6L-FNS8-A-1 | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in., Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3D6L-FNS8-A-1M-F2 | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in.,316 SS Bolt, Config.:2-Isolate&1-Equalize, Direct Mounting, FC-02 Cleaned | IMAGE |
| 3D6L-FNS8-A-F2 | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting, FC-02 Cleaned | IMAGE |
| 3D6L-FNS8-A-FB-ME | 316L SS | 3-valve Manifolds | Coplanar three-valve group,working pressure 6000psi, working temperature: -54℃ to 232℃; The inlet is 1/2"NPT female thread, the center distance of the outlet flange is 54mm; Composed of valve angular distribution; Bolts 7/16-20UNF×1.75" | IMAGE |
| 3D6L-FNS8-A-G | 316L SS | 3-valve Manifolds | 316L SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3D6L-FNS8-A-MFB-ME | 316L SS | 3-valve Manifolds | 316 6L, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3D6L-FNS8-A-P | 316L SS | 3-Valve Manifold | Body:316L SS, MWP:6,000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate & 1-Equalize, Direct Mounting | IMAGE |
| 3D6L-FNS8-A-P-1M | 316L SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3D6L-FNS8-A-P-1M-ME | 316L SS | 3-valve Manifolds | 316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3D6L-FNS8-A-P-M | 316L SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 1.75in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3D6L-FNS8-A-P-M-S | 316L SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 1.75in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3D6L-FNS8-A-P-S | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting,NACE MR 0175 | IMAGE |
| 3D6L-FNS8-A-S | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting,NACE MR 0175 | IMAGE |
| 3DD7-FNS8-A | Super Duplex | 3-valve Manifolds | Body:Super Duplex 2507, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DD7-FNS8-A-1M | Super Duplex | 3-valve Manifolds | 3D Series valves, MWP: 6000psig, working temperature -54℃ to 232℃, inlet and outlet of 1/2NPT female thread, Angle type, bolt of 1" stainless steel | IMAGE |
| 3DD7-FNS8-A-P-1M-ME | Super Duplex | 3-valve Manifolds | Duplex 2507, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DD7-FNS8-A-P-M-ME | Super Duplex | 3-valve Manifolds | Duplex 2507, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 1.75in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DM-FNS8-A | Monel 400 | 3-valve Manifolds | Body:Monel 400, MWP:5000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DM-FNS8-A-F2 | Monel 400 | 3-valve Manifolds | Body:Monel 400, MWP:5000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Config.:2-Isolate&1-Equalize, Direct Mounting, FC-02 Cleaned | IMAGE |
| 3DS1-FNS8-A | 321 SS | 3-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DS1-FNS8-A-1 | 321 SS | 3-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in., Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DS1-FNS8-A-1M-S | 321 SS | 3-valve Manifolds | 3D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20x 1.75" bolt, Bolt 316 SS. | IMAGE |
| 3DS4-FNS8-A | 304 SS | 3-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DS4-FNS8-A-F2 | 304 SS | 3-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Config.:2-Isolate&1-Equalize, Direct Mounting, FC-02 Cleaned | IMAGE |
| 3DSS-FNS8-A | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3DSS-FNS8-A-1 | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, Bolt: 7/16-20 x 3" | IMAGE |
| 3DSS-FNS8-A-1M | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, Bolt: 7/16-20×3"316 SS | IMAGE |
| 3DSS-FNS8-A-1M-S | 316 SS | 3-valve Manifolds | 3D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20UNF×3" bolt, Bolt 316 SS, NACE MR 0175. | IMAGE |
| 3DSS-FNS8-A-1-S | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Flange Fastener:7/16-20 UNF x 3in., Config.:2-Isolate&1-Equalize, Direct Mounting, NACE MR 0175 | IMAGE |
| 3DSS-FNS8-A-2 | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Flange Fastener:M10 x 40mm, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-A-2M | 316 SS | 3-valve Manifolds | 316 SS,3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange),1/2 Female NPT × Flange(MSS SP-99),Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C),Angle Pattern, Bolt:316 SS,M10 x 40 mm | IMAGE |
| 3DSS-FNS8-A-2M-F2 | 316 SS | 3-valve Manifolds | Maximum working pressure 6000psi, working temperature: -54 ℃ to 232 ℃; Imported 1/2 "NPT female thread, outlet flange, outlet flange center distance 54mm; valve angle installation; The bolt is M10 × 40mm, made of stainless steel, F2 cleaning | IMAGE |
| 3DSS-FNS8-A-F2 | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, FITOK FC-02 Cleaned | IMAGE |
| 3DSS-FNS8-A-FA | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern,IEC 61518 Type A. | IMAGE |
| 3DSS-FNS8-A-FA-F2 | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern,IEC 61518 Type A.with FC-02 cleaning and packing | IMAGE |
| 3DSS-FNS8-A-G | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:Graphtie, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-A-G-1-S | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, Bolt: 7/16-20 x 3" | IMAGE |
| 3DSS-FNS8-A-G-F54 | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:Graphtie, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Valve angled installation, the center distance of the inlet is 54mm. | IMAGE |
| 3DSS-FNS8-A-M | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-A-MFB-ME | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3DSS-FNS8-A-M-S | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles,316 SS Bolt, Config.:2-Isolate&1-Equalize, Direct Mounting, NACE MR 0175 | IMAGE |
| 3DSS-FNS8-A-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-A-P-1M | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in.,316 SS Bolt, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-A-P-FB | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(IEC 61518 Type B), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, Vent with Plug. | IMAGE |
| 3DSS-FNS8-A-P-M | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3DSS-FNS8-A-P-M-F2 | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 3DSS-FNS8-A-S | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting, NACE MR 0175 | IMAGE |
| 3DSS-FNS8-A-T | 316 SS | 3-valve Manifolds | 3D Series, MWP: 6000psig, working temperature -54℃ to 232℃, inlet and outlet are 1/2NPT female thread, Angle type, 1/4"NPT female thread hole +RB discharge valve | IMAGE |
| 5D6L-FNS8-A | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5D6L-FNS8-A-1 | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in., Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5D6L-FNS8-A-1M-S | 316L SS | 5-valve Manifolds | Body:316L SS,MWP:6,000psig, Packing:PTFE,Inlet:2Ports × 1/2in.(F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in.Stainless steel, Config.:2-Isolate, 2-Vent, & 1-Equalize, Direct Mounting, NACE MR 0175 | IMAGE |
| 5D6L-FNS8-A-F2 | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, FC-02 Cleaned | IMAGE |
| 5D6L-FNS8-A-G-P-M | 316L SS | 5-valve Manifolds | 316 L, 5D Series 5-valve Instrumentation Manifolds, 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C), Angle Pattern, Test Port with Plug | IMAGE |
| 5D6L-FNS8-A-G-P-S | 316L SS | 5-valve Manifolds | 316L SS, 5D Series 5-valve Instrumentation Manifolds, 1/2 Female NPT × Flange(MSS SP-99), Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C), Angle Pattern, Test Port 1/4 Female NPT with Plug, NACE MR0175 | IMAGE |
| 5D6L-FNS8-A-M | 316L SS | 5-valve Manifolds | 316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35,316 SS Bolt, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5D6L-FNS8-A-ME | 316L SS | 5-valve Manifolds | 316L, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting,316 SS handle | IMAGE |
| 5D6L-FNS8-A-M-S | 316L SS | 5-valve Manifolds | Coplanar five valve group, maximum working pressure 6000psi, working temperature: -54 ℃ to 232 ℃; The inlet is 1/2NPT female thread, the outlet is flange, and the center distance of the outlet flange is 54mm; Valve angle installation; The metal parts in | IMAGE |
| 5D6L-FNS8-A-P | 316L SS | 5-valve Manifolds | 316L SS, 5D Series 5-valve Manifolds, Direct Mount(transmitter with coplanar mounting flange), 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Process: 1/2 Female NPT, Instrument: Flange(MSS SP-99), Angle Pattern, Vent: 1/4 Female NPT with Plug | IMAGE |
| 5D6L-FNS8-A-P-1M-S | 316L SS | 5-valve Manifolds | 5D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20× 3" bolt, Bolt 316 SS,NACE MR0175. | IMAGE |
| 5D6L-FNS8-A-P-2MFB | 316L SS | 5-valve Manifolds | Co-planar five-port valve assembly, maximum working pressure 6000 psi, operating temperature: -54°C to 232°C; inlet is 1/2 NPT female thread, outlet is flanged, with a flange center distance of 54 mm; | IMAGE |
| 5D6L-FNS8-A-P-M | 316L SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5D6L-FNS8-A-S | 316L SS | 5-valve Manifolds | 316LSS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT, Outlet:Flange(Wafer), Vent:2Ports × 1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, NACE MR0175 | IMAGE |
| 5DD7-FNS8-A | Super Duplex | 5-valve Manifolds | Body:Super Duplex S32750, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting | IMAGE |
| 5DD7-FNS8-A-1MFB | Super Duplex | 5-valve Manifolds | Coplanar five valve group, maximum working pressure 6000psi, working temperature: -54 ℃ to 232 ℃; Imported 1/2NPT female thread, outlet flange, outlet flange center distance 54mm; valve angle installation; The bolt is 7/16-20NNF×3 ". | IMAGE |
| 5DD7-FNS8-A-P-M | Super Duplex | 5-valve Manifolds | Body:Super Duplex S32750, MWP:6000psig, Inlet:2Ports ×1/2in.(F)NPT, Outlet:Flange, Vent:1/4in.(F)NPT, Orifice:4mm, Cv:0.35,316 SS Bolt, Config.:2-Isolate, 2-Vent, &1-Equalize, Direct Mount, including Plug.The details refer to the sales drawing | IMAGE |
| 5DD7-FNS8-A-S | Super Duplex | 5-valve Manifolds | 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DS1-FNS8-A | 321 SS | 5-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DS1-FNS8-A-P | 321 SS | 5-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DS1-FNS8-A-P-1 | 321 SS | 5-valve Manifolds | 321 SS, 5-valve Manifolds, MWP: 6000psig, Inlet: 2Ports × 1/2 Female NPT, Outlet: Flange, Vent: 1/4 Female NPT with Plug, Angel Pattern, Flange Bolt: 7/16-20 UNF×3" | IMAGE |
| 5DS4-FNS8-A-F2 | 304 SS | 5-Valve Manifolds | 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig, -54°C to 232°C, Angle Pattern，FITOK FC-02 Cleaned | IMAGE |
| 5DS4-FNS8-A-P | 304 SS | 5-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-1 | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in., Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A-1M | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in.(F)NPT, Outlet:Flange, Vent:1/4in.(F)NPT, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in,316 SS Bolt, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mount | IMAGE |
| 5DSS-FNS8-A-1M-F2 | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Inlet:2Ports × 1/2in.(F)NPT, Outlet:Flange, Vent:1/4in.(F)NPT, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in,316 SS Bolt，Cleaning and packaging comply with ASTM G93C level requirements。 | IMAGE |
| 5DSS-FNS8-A-1M-S | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in.(F)NPT, Outlet:Flange, Vent:1/4in.(F)NPT, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in,316 SS Bolt, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mount, NACE MR0175. | IMAGE |
| 5DSS-FNS8-A-1-S | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Flange Fastener:7/16-20 UNF x 3in., Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, NACE MR 0175 | IMAGE |
| 5DSS-FNS8-A-B | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, Ball Stem Tip | IMAGE |
| 5DSS-FNS8-A-F2 | 316 SS | 5-valve Manifolds | 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig, -54°C to 232°C, Angle Pattern，FITOK FC-02 Cleaned | IMAGE |
| 5DSS-FNS8-A-F54 | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-FB | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount (transmitter with coplanar mounting flange), 1/2 Female NPT × Flange (IEC 61518 Type B), 1/4 Female NPT Vent, PTFE Packing, 6000 psig (414 bar), -65°F to 450°F (-54°C to 232°C). | IMAGE |
| 5DSS-FNS8-AG | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:Graphite, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A-G | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-G-2 | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -65°F to 1000°F (-54°C to 538°C)Angle Pattern | IMAGE |
| 5DSS-FNS8-A-G-ME | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-G-P | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C), Angle Pattern, Test Port with Plug | IMAGE |
| 5DSS-FNS8-A-M | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35,316 SS Bolt, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A-ME | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting,316 SS handle | IMAGE |
| 5DSS-FNS8-A-M-F2 | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35,316 SS Bolt, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A-MFB-ME | 316 SS | 5-valve Manifolds | 316 SS,, 1/2 Female NPT × Flange（IEC 61518 typeB）× 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-P | 316 SS | 5-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent, & 1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A-P-1 | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in., Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-A-P-1M | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in.(F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in,316 SS Bolt, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mount | IMAGE |
| 5DSS-FNS8-A-P-2-F54-Q87894 | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C),Angle Pattern, Test Port with Plug | IMAGE |
| 5DSS-FNS8-A-P-2MFB | 316 SS | 5-valve Manifolds | Co-planar five-port valve assembly, maximum working pressure 6000 psi, operating temperature: -54°C to 232°C; inlet is 1/2 NPT female thread, outlet is flanged, with a flange center distance of 54 mm; valve installed at an angle; relief port with plug. | IMAGE |
| 5DSS-FNS8-A-PAK | 316 SS | 5-valve Manifolds | 5-valve manifold,316 SS, inlet: 1/2in. (F)NPT, Outlet:Flange, details as per sales drawing | IMAGE |
| 5DSS-FNS8-A-P-F2 | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange, Vent:1/4in. (F)NPT w/ Plug, Orifice:4mm, Cv:0.35, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, FC-02 Cleaned | IMAGE |
| 5DSS-FNS8-A-P-F54 | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C),vent with plug, Angle Pattern | IMAGE |
| 5DSS-FNS8-A-P-FB | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount (transmitter with coplanar mounting flange),1/2 Female NPT × Flange (MSS SP-99), 1/4 Female NPT (with Plug) Vent, PTFE Packing, 6000 psig, 54°C to 232°C, Angle Pattern. | IMAGE |
| 5DSS-FNS8-A-P-M | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-P-ME | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT,T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Vertically Mounted | IMAGE |
| 5DSS-FNS8-A-P-MFB | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-P-MFB-ME | 316 SS | 5-valve Manifolds | 316 SS,, 1/2 Female NPT × Flange（IEC 61518 typeB）× 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 5DSS-FNS8-A-P-S | 316 SS | 5-valve Manifolds | 316 SS, 5D Series Direct Mount 5-valve Manifolds, PTFE Packing, 1/2 Female NPT × Flange × 1/4 Female NPT, 6000psig(414bar), -54℃ to 232℃, Angle Pattern, NACE MR0175 | IMAGE |
| 5DSS-FNS8-A-S | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange(Wafer), Vent:2Ports x 1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, NACE MR0175 | IMAGE |
| 2D6L-FNS8-A | 316L SS | 2-valve Manifolds | 316L SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting | IMAGE |
| 2D6L-FNS8-A-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting, FC-02 Cleaned | IMAGE |
| 2D6L-FNS8-A-P | 316L SS | 2-valve Manifolds | Coplanar two valve group, maximum working pressure 6000psi, working temperature: -54 ℃ to 232 ℃; Imported with 1/2 "NPT female thread and exported with flange; Valve angle installation; Graphite filler; 1/4NPT female thread drain port with plug. | IMAGE |
| 2D6L-FNS8-A-S | 316L SS | 2-valve Manifolds | 316L SS, 2D Series 2-valve Instrumentation Manifolds, MWP: 6000psig, Packing: PTFE, Inlet: 1/2in. (F)NPT, Outlet: Flange, Vent:1/4in. (F)NPT, NACE MR0175 | IMAGE |
| 2DS4-FNS8-A-F2 | 304 SS | 2-valve Manifolds | 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting, FC-02 Cleaned | IMAGE |
| 2DSS-FNS8-A | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 2DSS-FNS8-A-1M | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Flange Fastener:7/16-20 UNF x 3in.,316 SS Bolt, Config.:1-Isolate&1-Vent, Direct Mounting | IMAGE |
| 2DSS-FNS8-A-1M-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Flange Fastener:7/16-20 UNF × 3in.,316 SS Bolt,Cleaning and packaging comply with ASTM G93C level requirements。 | IMAGE |
| 2DSS-FNS8-A-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting, FC-02 Cleaned | IMAGE |
| 2DSS-FNS8-A-M | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 2DSS-FNS8-A-M-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 2DSS-FNS8-A-P | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting | IMAGE |
| 2DSS-FNS8-A-P-1 | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, Direct Mount, 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, 6000psig(414bar), -54℃ to 232℃, Angle Pattern, Flange Bolts 7/16-20UNF×3" | IMAGE |
| 2DSS-FNS8-A-P-M | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | IMAGE |
| 2DSS-FNS8-A-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2D Series Direct Mount 2-valve Manifolds, PTFE Packing, 1/2 Female NPT × Flange × 1/4 Female NPT, 6000psig(414bar), -54℃ to 232℃, Angle Pattern, NACE MR0175 | IMAGE |
| 2R6L-FNS4-NS4-H-P | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/4in. (F)NPT,Outlet:1/4in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2R6L-FNS8-NS8-H | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2R6L-FNS8-NS8-H-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig,Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, Al T-bar Handles, FC-02 Cleaned | IMAGE |
| 2R6L-FNS8-NS8-H-P | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet: 1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.: 1-Isolate&1-Vent, Al T-bar Handles | IMAGE |
| 2R6L-FNS8-NS8-H-P-ME | 316L SS | 2-valve Manifolds | Body:316 SS, MWP:5,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting， with 1/4 NPT female plug, 316SS handle | IMAGE |
| 2R6L-FNS8-NS8-H-P-S | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet: 1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.: 1-Isolate&1-Vent, Al T-bar Handles, NACE MR 0175 | IMAGE |
| 2R6L-FNS8-NS8-H-Q88510 | 316L SS | 2-valve Manifolds | 316/316L SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2R6L-FNS8-NS8-H-S | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet: 1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.: 1-Isolate&1-Vent, Al T-bar Handles, NACE MR 0175 | IMAGE |
| 2RD7-FNS8-NS8-H | Super Duplex | 2-valve Manifolds | Body:Super Duplex S32750, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Block&1-Vent, Remote Mounting | IMAGE |
| 2RH6L-FNS8-NS8-H | 316L SS | 2-valve Manifolds | 316L SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(690bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RH6L-FNS8-NS8-H-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:1/2in.(F)NPT, Outlet: 1/2in. (M)NPT, Vent:1/4in.(F)NPT, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line MountingFC-02 Cleaned | IMAGE |
| 2RHC-FNS8-NS8-H | Alloy C-276 | 2-valve Manifolds | Body:Alloy C-276, MWP:6000psig,Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RHC-FNS8-NS8-H-P-S | Alloy C-276 | 2-valve Manifolds | AlloyC-276, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug,NACE MR0175 | IMAGE |
| 2RHSS-FNS8-NS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(690bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RHSS-FNS8-NS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RHSS-FNS8-NS8-H-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting,NACE MR0175 | IMAGE |
| 2RSS-FNS12-NS8-H-P | 316 SS | 2-valve Manifolds | Remote two-valve assembly, maximum working pressure 6000 psi, operating temperature range: -54°C to 232°C; inlet is 3/4"NPT female thread, outlet is 1/2"NPT male thread; valves are installed horizontally; 1/4"NPT female thread test port with plug | IMAGE |
| 2RSS-FNS4-NS4-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/4in. (F)NPT,Outlet:1/4in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2RSS-FNS8-NS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RSS-FNS8-NS8-H-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line MountingFC-02 Cleaned | IMAGE |
| 2RSS-FNS8-NS8-H-G | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphite, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, T-bar Handles, In-line Mounting | IMAGE |
| 2RSS-FNS8-NS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug | IMAGE |
| 2RSS-FNS8-NS8-H-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR 0175 | IMAGE |
| 2RSS-FNS8-NS8-H-T | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Bleed Valves, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RHSS-FNS4-V | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/4 Female NPT × 1/4 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(649bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 2RHSS-FNS4-V-P | 316 SS | 2-valve Manifolds | 316 SS, 2-valve Instrumentation Manifolds, MWP: 10000psig, Packing: PTFE, Inlet&Outlet: 1/4 Female NPT, Vent: 1/4 Female NPT with Plug, Valves Vertically Mounted | IMAGE |
| 2RHSS-FNS4-V-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2-valve Instrumentation Manifolds, MWP: 10000psig, Packing: PTFE, Inlet&Outlet: 1/4 Female NPT, Vent: 1/4 Female NPT with Plug, Valves Vertically Mounted, NACE MR0175 | IMAGE |
| 2D6L-FNS8-C | 316L SS | 2-valve Manifolds | 2-Valve Manifold,Body:316LSS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Direct Mounting | IMAGE |
| 2DSS-FNS8-C | 316L SS | 2-valve Manifolds | 2-Valve Manifold,Body:316 SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Direct Mounting | IMAGE |
| 2R6L-NS12-FMS20-H-P | 316L SS | 2-valve Manifolds | 2R Series, set pressure rangmaximum working pressure:41.4MPa,working temperature:-54~232℃,inlet：3/4 Male NPT,outlet:M20×1.5 Female | IMAGE |
| 2R6L-NS8-FMS20-H | 316L SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (N)NPT, Outlet: M20*1.5 Female Metric Thread, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.: 1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2R6L-NS8-FMS20-H-ME | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP: 6000psig, Packing: PTFE, Inlet: 1/2 Male NPT, Outlet: M20*1.5 Female Metric Thread, Vent: 1/4 Female NPT, Valves Horizontally Mounted | IMAGE |
| 2R6L-NS8-FMS20-H-P-S | 316L SS | 2-valve Manifolds | Body:316L SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (N)NPT, Outlet: M20*1.5 Female Metric Thread, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.: 1-Isolate & 1-Vent, In-line Mounting, NACE MR0175 | IMAGE |
| 2R6L-NS8-FNS8-H | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2R6L-NS8-FNS8-H-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, FC-02 Cleaned | IMAGE |
| 2R6L-NS8-FNS8-H-G-ME | 316L SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, In&Out: 1/2 Male NPT × 1/2 Female NPT, Vent: 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -54℃ to 649℃, Valves Horizontally Mounted | IMAGE |
| 2R6L-NS8-FNS8-H-G-P | 316L SS | 2-Valve Manifold | 316L SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 male NPT × 1/2 Female NPT × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C), Valves Horizontally Mounted, Test Port with Plug | IMAGE |
| 2R6L-NS8-FNS8-H-ME | 316L SS | 2-Valve Manifold | Body:316L SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting,customized 316SS components as drawing | IMAGE |
| 2R6L-NS8-FNS8-H-P | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2R6L-NS8-FNS8-H-P-FOG | 316L SS | 2-valve Manifolds | Remote two-valve group, maximum working pressure of 6000psi, working temperature: -54℃ to 232℃; The inlet is 1/2"NPT male thread, the outlet is 1/2"NPT female thread; Valve horizontal installation; 1/4"NPT female thread test hole with plug,FOG cleaning | IMAGE |
| 2R6L-NS8-FNS8-H-P-ME | 316L SS | 2-valve Manifolds | 316L, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug | IMAGE |
| 2R6L-NS8-FNS8-H-P-ME-SEALANT-CPFX | 316L SS | 2-valve Manifolds | 2R6L-NS8-FNS8-H-P-ME without PTFE Tape Pipe Thread Sealant, part number for repair only | IMAGE |
| 2R6L-NS8-FNS8-H-P-S | 316L SS | 2-valve Manifolds | Body:316L SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting, NACE MR0175 | IMAGE |
| 2R6L-NS8-FNS8-H-S-ME | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-Valve Manifold, Packing: PTFE, MWP: 6000psig, -54℃ to 232℃, Inlet: 1/2 Male NPT, Outlet: 1/2 Female NPT, Vent: 1/4 Female NPT, Valves Horizontally Mounted, NACR MR0175 | IMAGE |
| 2R6L-NS8-FNS8-H-V8-P-S | 316L SS | 2-Valve Manifold | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP: 5000psig, Temperature Range: -54 to 232℃, Inlet: 1/2 Male NPT, Outlet: 1/2 Female NPT, Vent: 1/2 Female NPT with Plug, Valves Horizontally Mounted, NACE MR0175 | IMAGE |
| 2RD7-NS8-FNS8-H | Super Duplex | 2-valve Manifolds | Super duplex 2507, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RD7-NS8-FNS8-H-P-ME | Super Duplex | 2-Valve Manifolds | Remote two valve group, valve body material is 2507 duplex steel material, maximum working pressure is 6000psi, working temperature: -54 ℃ to 232 ℃; Imported with 1/2 "NPT male thread, exported with 1/2" NPT female thread, valve installed horizontally; | IMAGE |
| 2RD7-NS8-FNS8-H-P-S | Super Duplex | 2-valve Manifolds | Body:Duplex2507, MWP:6000psig,Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR 0175. | IMAGE |
| 2RD7-NS8-FNS8-H-S | Super Duplex | 2-valve Manifolds | Body: Super Duplex S32750, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.:1-Block&1-Vent, Aluminum T-bar Handles, NACE MR0175 | IMAGE |
| 2RHC-NS8-FNS8-H-P | Alloy C-276 | 2-valve Manifolds | Body:Alloy C-276, MWP:6000psig,Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2RHC-NS8-FNS8-H-V8-P-S | Alloy C-276 | 2-Valve Manifold | Alloy C-276, 2R Series 2-valve Instrumentation Manifolds, MWP: 6000psig, Temperature Range: -54 to 232℃, Inlet: 1/2 Male NPT, Outlet: 1/2 Female NPT, Vent: 1/2 Female NPT with Plug, Valves Horizontally Mounted, NACE MR0175 | IMAGE |
| 2RHSS-NS12-NS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:3/4in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RHSS-NS12-NS8-H-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:3/4in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting NACE MR0175 | IMAGE |
| 2RHSS-NS8-FNS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig,Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RHSS-NS8-FNS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-Valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:1/2 (M)NPT, Outlet:1/2 (F)NPT, Vent:1/4 (F)NPT with Plug, Valves Horizontally Mounted, Orifice:0.157", Aluminum alloy Handle, Config.:1-Isolate&1-Vent | IMAGE |
| 2RHSS-NS8-FNS8-H-P-S | 316 SS | 2-valve Manifolds | Body:316SS, MWP:10,000psig, Packing:PTFE,Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm,Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting,NACE MR0175 | IMAGE |
| 2RS1-NS8-FNS8-H-P | 321 SS | 2-valve Manifolds | 321 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, 6000psig(414bar), -54℃ to 232℃, Valves Horizontally Mounted, Test Port with Plug | IMAGE |
| 2RS4-NS8-FNS8-H-F2 | 304 SS | 2-valve Manifolds | 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RSS-NS12-FNS12-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:3/4in. (M)NPT, Outlet:3/4in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2RSS-NS12-FNS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:3/4in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS12-FNS8-H-G-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing: Graphite, Inlet:3/4in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT,with plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS4-FNS4-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig,Packing:PTFE, Inlet:1/4in. (M)NPT, Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS4-FNS4-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig,Packing:PTFE, Inlet:1/4in. (M)NPT, Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS4-FNS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/4in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS8-FMS20-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (N)NPT, Outlet: M20*1.5 Female Metric Thread, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.: 1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS8-FMS20-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (N)NPT, Outlet: M20*1.5 Female Metric Thread, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.: 1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS8-FMS20-H-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (N)NPT, Outlet: M20×1.5（F）, Vent:1/4"(F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.: 1-Isolate&1-Vent, In-line Mounting,NACE MR0175 | IMAGE |
| 2RSS-NS8-FNS4-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS8-FNS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RSS-NS8-FNS8-H-F2 | 316 SS | 2-valve Manifolds | 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | IMAGE |
| 2RSS-NS8-FNS8-H-G | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -54°C to 649 C, Valves Horizontally Mounted | IMAGE |
| 2RSS-NS8-FNS8-H-G-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -54℃ to 649℃, Valves Horizontally Mounted | IMAGE |
| 2RSS-NS8-FNS8-H-G-P-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -54°C to 649°C, Valves Horizontally Mounted, Test Port with Plug | IMAGE |
| 2RSS-NS8-FNS8-H-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | IMAGE |
| 2RSS-NS8-FNS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug | IMAGE |
| 2RSS-NS8-FNS8-H-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:1-Block&1-Vent, Aluminum T-bar Handles. NACE MR0175 | IMAGE |
| 2RSS-NS8-FNS8-H-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig,Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR 0175 | IMAGE |
| 2RSS-NS8-FNS8-H-T | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Bleed Valves, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 3DSS-FNS8-C | 316 SS | 3-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange (Coplanar), Vent:/, Cv:0.35, Al T-bar Handles, Config.:2-Isolate & 1-Equalize, Direct Mounting | IMAGE |
| 3DSS-FNS8-C-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange (Coplanar), Vent:1/4in (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:2-Isolate,&1-Equalize, Direct Mount, Al T-bar Handles | IMAGE |
| 3DSS-FNS8-C-T | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange (Coplanar), Vent:1/4in (F)NPT with Bleed Valves, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate,&1-Equalize, Direct Mounting | IMAGE |
| 5R6L-FNS8-L | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5R6L-FNS8-L-P | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5RS4-FNS8-L | 304 SS | 5-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Remote Mounting | IMAGE |
| 5RSS-FNS8-L | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, In-line Mounted | IMAGE |
| 5RSS-FNS8-L-ME | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, In-line Mounted,316 SS handle | IMAGE |
| 5RSS-FNS8-L-P | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5RSS-FNS8-L-S | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting, NACE MR 0175 | IMAGE |
| 5R6L-FNS8-V | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5R6L-FNS8-V-G-ME | 316L SS | 5-valve Manifolds | 316 SS, 5R Series 5-valve Instrumentation Manifolds, Remote Mount, In&Out: 1/2 Female NPT, Vent: 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -54℃ to 649℃, Valves Vertically Mounted | IMAGE |
| 5R6L-FNS8-V-ME | 316L SS | 5-valve Manifolds | 316L SS, MWP:6000psig, Packing: PTFE, Inlet&Outlet: 1/2in. (F)NPT, Vent:1/4in. (F)NPT, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5R6L-FNS8-V-P | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5R6L-FNS8-V-P-ME | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT, Outlet:2Ports × 1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5R6L-FNS8-V-P-S | 316L SS | 5-valve Manifolds | 5R Series, MWP:41.4MPa, working temperature:-54~232℃, inlet and outlet:1/2NPT Female,NACE MR0175 . | IMAGE |
| 5R6L-FNS8-V-S | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting；NACE MR 0175 | IMAGE |
| 5R6L-NS8-V-G | 316L SS | 5-valve Manifolds | Remote five valve group, maximum working pressure 6000psi, working temperature: -54 ℃ to 649 ℃; The inlet and outlet are 1/2 "NPT male threads, forming a vertical distribution of the valve with graphite packing. | IMAGE |
| 5RM-FNS8-V-F2 | Monel | 5-valve Manifolds | 5-valve Manifold, Body:Monel, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Config.:2-Isolate, 2-Vent&1-Equalize, Valves Vertically Mounted, FC-02 Cleaned | IMAGE |
| 5RS1-FNS8-V-P | 321 SS | 5-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 5RSS-FNS4-V-G-P-ME | 316 SS | 5-valve Manifolds | 5R series five-valve group, maximum working pressure 41.4MPa, working temperature -54℃-649℃; Inlet and outlet are 1/4NPT female thread, valve body vertically mounted, flexible graphite packing, | IMAGE |
| 5RSS-FNS4-V-P | 316 SS | 5-valve Manifolds | 316 SS, 5R series instrument two valve group, remote installation, process interface with 1/4 NPT female thread, instrument interface with 1/2 NPT female thread, drain port with 1/4 NPT female thread, drain port with plug, 6000 PSI. | IMAGE |
| 5RSS-FNS4-V-P-ME | 316 SS | 5-valve Manifolds | 5R series five-valve group, maximum working pressure 41.4MPa, working temperature -54℃-232℃; Inlet and outlet are 1/4NPT female thread, valve body vertically mounted, flexible graphite packing, with plug | IMAGE |
| 5RSS-FNS8-V | 316 SS | 5-valve Manifolds | 316 SS, 5R Series 5-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 5RSS-FNS8-VB | 316 SS | 5-valve Manifolds | 316 SS, 5R Series 5-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted, Double-equalize | IMAGE |
| 5RSS-FNS8-V-G | 316 SS | 5-valve Manifolds | 316 Stainless Steel, 5R Series 5-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT, 1/4 Female NPT Vent, Graphite Packing, 6000 psig, Valves Vertically Mounted | IMAGE |
| 5RSS-FNS8-V-P | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Remote Mounting | IMAGE |
| 2D6L-FNS8-V-P | 316L SS | 2-valve Manifolds | Body:316L, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange,, Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:1-Block & 1-Vent , Remote Mounting | IMAGE |
| 2D6L-FNS8-V-P-MFB-ME | 316L SS | 2-valve Manifolds | Body:316L, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, IEC 61518 typeB | IMAGE |
| 2DSS-FNS8-V | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Direct Mounting, Valves Vertically Mounted. | IMAGE |
| 2DSS-FNS8-V-MFB-ME | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, IEC 61518 typeB | IMAGE |
| 2DSS-FNS8-V-P-MFB | 316 SS | 2-valve Manifolds | 2-valve manifold | IMAGE |
| 2DSS-FNS8-V-P-MFB-ME | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, IEC 61518 typeB | IMAGE |
| 2DSS-FNS8-V-S | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Direct Mounting, Valves Vertically Mounted. | IMAGE |
| 2R6L-FNS4-L | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/4 Female NPT ×1/4 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves In-line Mounted | IMAGE |
| 2R6L-FNS8-L | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2R6L-FNS8-L-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, FC-02 Cleaned | IMAGE |
| 2R6L-FNS8-L-P | 316L SS | 2-valve Manifolds | 316L SS Material, 2-valve manifolds, Remote mount type, 1/2 female NPT Inlet and outle, body style: valves in-line mounted, Test&plug: 1/4 female NPT with Plug | IMAGE |
| 2R6L-FNS8-L-S | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting；NACE MR 0175 | IMAGE |
| 2R6L-NS8-FNS8-L | 316L SS | 2-valve Manifolds | 2-valve manifold, remote mount, 316L, inlet: 1/2”NPT male, outlet: 1/2”NPT female, body style:valves in-line mounted | IMAGE |
| 2RHD7-FNS8-L | Super Duplex | 2-Valve Mainifolds | 2-Valve Manifolds, Body: Super Duplex, MWP 10000 psi,Packing: PTFE, Inlet: 1/2 (F)NPT, Outlet: 1/2 (F)NPT, Vent: 1/4 (F)NPT,Cv: 0.35,Al T-bar Handles, Config: 1-Isolate & 1-Vent, Remote Mounting | IMAGE |
| 2RHSS-FNS8-L | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT, PTFE Packing, Valves In-line Mounted | IMAGE |
| 2RHSS-FNS8-L-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting, NACE MR 0175 | IMAGE |
| 2RS1-FNS8-L-P | 321 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | IMAGE |
| 2RSS-FNS8-L | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves In-line Mounted | IMAGE |
| 2RSS-FNS8-L-G | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves In-line Mounted | IMAGE |
| 2RSS-FNS8-L-G-F2 | 316 SS | 2-Valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves In-line Mounted | IMAGE |
| 2RSS-FNS8-L-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves In-line Mounted, Test Port with Plug | IMAGE |
| 2RSS-FNS8-L-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves In-line Mounted, Test Port with Plug,Nace MR0175 Compliant | IMAGE |
| 2RSS-FNS8-L-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting, NACE MR 0175 | IMAGE |
| 3DSS-F-V | 316 SS | 3-valve Manifolds | Body:316SS,MWP:6,000psig,Packing:PTFE,Inlet&Outlet:Flange,Vent:No, Orifice:4mm, Cv:0.35,Config.:2-Isolate,& 1-Equalize,Direct Mounting | IMAGE |
| 3DSS-F-VG-M | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:Graphite, Inlet&Outlet:Flange, Vent:No, Orifice:4mm, Cv:0.35, Config.:2-Isolate,&1-Equalize, Direct Mounting | IMAGE |
| 3DSS-F-V-P | 316 SS | 3-valve Manifolds | 316 SS 3D Series 3-Way manifolds, direct mount, Inlet & Outlet: Flange, valves vertically mounted, with 1/4 female NPT plug,as per drawing | IMAGE |
| 3R6L-FNS8-V | 316L SS | 3-valve Manifolds | Body:316L SS,MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3R6L-FNS8-V-F2 | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, FC-02 Cleaned | IMAGE |
| 3R6L-FNS8-V-G-P-ME | 316L SS | 3-valve Manifolds | 3R Series 3-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C), Valves Vertically Mounted | IMAGE |
| 3R6L-FNS8-V-P | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports × 1/2in. (F)NPT, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3R6L-FNS8-V-P-S | 316L SS | 3-valve Manifolds | 316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT, Outlet:2Ports × 1/2in. (F)NPT, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Complies with NACE MR0175。 | IMAGE |
| 3RD7-FNS8-V | Super Duplex | 3-valve Manifolds | Body:Super Duplex 2507, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3RHS1-FNS8-V-G-P | 321 SS | 3-valve Manifolds | Remote installation of three valve group, maximum working pressure of 10000PSI, working temperature: -54 ℃ to 649 ℃, inlet and outlet are both 1/2 NPT female threads, forming a vertical distribution of valves, graphite packing. | IMAGE |
| 3RHSS-FNS4-V-P | 316 SS | 3-valve Manifolds | 316 SS, 3RH Series 3-valve Instrumentation Manifolds, Remote Mount, 1/4 Female NPT × 1/4 Female NPT × 1/4 Female NPT with Plug, PTFE Packing, 10,000psig(690bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 3RHSS-FNS8-V | 316 SS | 3-valve Manifolds | 316 SS, 3RH Series 3-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(690bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 3RHSS-FNS8-V-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:10,000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3RS1-FNS8-V | 321 SS | 3-valve Manifolds | Body:321 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3RS1-FNS8-V-P | 321 SS | 3-valve Manifolds | Remote three valve group, maximum working pressure 6000psi, working temperature: -54 ℃ to 232 ℃; Import and export are 1/2 "NPT female threads; Valve vertically installed with plug | IMAGE |
| 3RS4-FNS8-V | 304 SS | 3-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3RSS-FNS4-V | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/4in. (F)NPT, Outlet:1/4in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3RSS-FNS4-V-F2 | 316 SS | 3-valve Manifolds | Remote three-valve assembly, MWP: of 6, 000 psi, operating temperature: -54℃ to 232℃, 1/4"NPT female thread for inlet and outlet, Valves are installed vertically, specially cleaned and packed | IMAGE |
| 3RSS-FNS4-V-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/4in. (F)NPT, Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 3RSS-FNS4-V-P-F2 | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/4in. (F)NPT, Outlet:1/4in. (F)NPT, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, FC-02 Cleaned | IMAGE |
| 3RSS-FNS8-V | 316 SS | 3-valve Manifolds | 316 SS, 3R Series 3-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | IMAGE |
| 3RSS-FNS8-V-F2 | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:/, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting, FC-02 Cleaned | IMAGE |
| 3RSS-FNS8-V-G | 316 SS | 3-valve Manifolds | 316 SS, 3R Series 3-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar),-54°C to 649°C, Valves Vertically Mounted | IMAGE |
| 3RSS-FNS8-V-G-P-ME | 316 SS | 3-valve Manifolds | 316 SS, 3R Series 3-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, Graphite Packing, 6000psig(414bar), -65°F to 1200°F(-54°C to 649°C), Valves Vertically Mounted | IMAGE |
| 3RSS-FNS8-V-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | IMAGE |
| 5D6L-FNS8-C | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5D6L-FNS8-C-Q88510 | 316L SS | 5-valve Manifolds | Body:316/316L SS,, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | IMAGE |
| 5D6L-FNS8-C-S | 316L SS | 5-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT,Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting，NACE | IMAGE |
| 5DD7-FNS8-C-G-P | Super Duplex | 5-valve Manifolds | Body:316LSS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT with plug, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting. | IMAGE |
| 5DSS-FNS8-C | 316 SS | 5-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting | IMAGE |
| 5DSS-FNS8-C-G-P | 316 SS | 5-valve Manifolds | Body:316LSS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT with plug, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting. | IMAGE |
| 5DSS-FNS8-C-P-F2 | 316 SS | 5-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PEEK, Inlet:1/2in. (F)NPT, Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting, FC-02 | IMAGE |
| 5DSS-FNS8-C-S | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange(Coplanar), Vent:2Ports x 1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting, NACE MR0175 | IMAGE |
| 2D6L-FNS8-L | 316L SS | 2-valve Manifolds | 316L SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting | No Image |
| 2DSS-FNS8-L | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Direct Mounting | No Image |
| 2DSS-FNS8-L-P | 316 SS | 2-valve Manifolds | 2D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange. | No Image |
| 2DSS-FNS8-L-P-M | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate | No Image |
| 2DSS-FNS8-L-S | 316 SS | 2-valve Manifolds | 316 SS, 2D Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Direct Mounting, NACE MR 0175 | No Image |
| 2DSS-FNS8-L-T | 316 SS | 2-valve Manifolds | 2D Series, MWP: 6000psig, working temperature -54℃ to 232℃, inlet and outlet are 1/2NPT female thread, valves are collinear distribution, 1/4"NPT female thread hole +RB discharge valve | No Image |
| 2DSS-NFL8-V | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. double ferrules port, Outlet:Flange, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Direct Mounting, Valves Vertically Mounted. | No Image |
| 2R6L-FMS20-H | 316L SS | 2-valve Manifolds | The maximum working pressure is 6000psi. The operating temperature is -54℃ to 204℃. The inlet and outlet are M20×1.5 metric female thread; Horizontal valve installation | No Image |
| 2R6L-FMS20-MS20-H | 316L SS | 2-valve Manifolds | 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:M20*1.5 Female Metric Thread, Outlet:M20*1.5 Male Metric Thread. | No Image |
| 2R6L-FNS12-FNS8-H-P | 316L SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 3/4 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug | No Image |
| 2R6L-FNS8-A | 316L SS | 2-valve Manifolds | 2-valve Manifold, 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2R6L-FNS8-A-P | 316L SS | 2-valve Manifolds | Body:316L, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2R6L-FNS8-H | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2R6L-FNS8-H-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, FC-02 Cleaned | No Image |
| 2R6L-FNS8-H-P | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate,&1-Vent, Remote Mounting | No Image |
| 2R6L-FNS8-H-P-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate,&1-Vent, Remote Mounting | No Image |
| 2R6L-FNS8-H-P-ME | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate,&1-Vent, Remote Mounting | No Image |
| 2R6L-FNS8-H-Q86356 | 316L SS | 2-valve Manifolds | 316/316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2R6L-FNS8-H-S | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, NACE MR0175-compliant | No Image |
| 2R6L-FNS8-NS8-V | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | No Image |
| 2R6L-MS20-FMS20-H-P | 316L SS | 2-valve Manifolds | 316L SS Material, 2-valve manifolds, Remote mount type, 1/2'' male MS20*1.5 Inlet, 1/2'' female MS20*1.5 outlet, body style: valves horizontally mounted, Test&plug: 1/4 female NPT with Plug | No Image |
| 2R6L-NS8-H | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2R6L-NS8-H-F2 | 316L SS | 2-valve Manifolds | 316L SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting, FC-02 Cleaned | No Image |
| 2R6L-NS8-H-P-S | 316L SS | 2-valve Manifolds | Body:Duplex2507, MWP:6000psig,Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR 0175. | No Image |
| 2R6L-NS8-H-S | 316L SS | 2-valve Manifolds | 2R Series, MWP:41.4MPa, working temperature:-54~232℃, inlet and outlet:1/2NPT male .NACE MR 0175 | No Image |
| 2R6L-RT8-FRP8-H | 316L SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet&Outlet:1/2in. BSPT, Vent:1/2in. (F)BSPP, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, Remote Mounting | No Image |
| 2RD7-FNS8-H | Super Duplex | 2-valve Manifolds | Body:Super Duplex S32750, MWP:6,000psig, Packing:PTFE, Process:1/2in. (F)NPT, Instrument:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Block & 1-Vent, Remote Mounting | No Image |
| 2RD7-NS8-H | Super Duplex | 2-valve Manifolds | Body:Super Duplex S32750, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Block&1-Vent, Remote Mounting | No Image |
| 2RH6L-FNS8-H | 316L SS | 2-valve Manifolds | 316LSS, 2RH Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet/ Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RHC-NS8-H | Alloy C-276 | 2-valve Manifolds | Alloy C-276, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 2RHSS-FNS4-H | 316 SS | 2-valve Manifolds | 316 SS, 2-valve Instrumentation Manifolds, MWP: 1000psig, Packing: PTFE, Inlet&Outlet: 1/4 Female NPT, Vent: 1/4 Female NPT, Orifice: 4mm, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RHSS-FNS4-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2-valve Instrumentation Manifolds, MWP: 1000psig, Packing: PTFE, Inlet&Outlet: 1/4 Female NPT, Vent: 1/4 Female NPT with Plug, Valves Horizontally Mounted | No Image |
| 2RHSS-FNS8-A-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2RHSS-FNS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet/ Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RHSS-FNS8-H-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet/ Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RHSS-FNS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RHSS-FNS8-H-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR0175 | No Image |
| 2RHSS-FRT8-H-M | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female ISO Tapered Thread × 1/2 Female ISO Tapered Thread ×1/4 Female NPT, Valves Horizontally Mounted, stainless steel handle | No Image |
| 2RHSS-NS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(690bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 2RHSS-NS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:10,000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RHSS-NS8-H-S | 316 SS | 2-valve Manifolds | 316 SS, 2RH Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 10,000psig(690bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, NACE MR0175 | No Image |
| 2RS1-FMS20-MS20-H | 321 SS | 2-valve Manifolds | 321 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:M20*1.5 Female Metric Thread, Outlet:M20*1.5 Male Metric Thread, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RS1-FNS8-A | 321 SS | 2-valve Manifolds | 321SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | No Image |
| 2RS1-FNS8-A-G-P | 321 SS | 2-valve Manifolds | 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphite, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2RS1-FNS8-A-P | 321 SS | 2-valve Manifolds | 321 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig, -54°C to 232°C, Angle Pattern, Test Port with Plug | No Image |
| 2RS1-FNS8-H | 321 SS | 2-valve Manifolds | 2R Series, MWP:41.4MPa, working temperature:-54~232℃, inlet and outlet:1/2NPT Female,Material:321 SS. | No Image |
| 2RS4-FNS8-H-F2 | 304 SS | 2-valve Manifolds | 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, FC-02 Cleaned | No Image |
| 2RS4-FNS8-H-P | 304 SS | 2-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, Al T-bar Handles | No Image |
| 2RS4-FNS8-NS8-H-P | 304 SS | 2-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RS4-MS20-FMS20-H-P | 304 SS | 2-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:M20*1.5 Male Metric Thread, Outlet:M20*1.5 Female Metric Thread, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RS4-NS8-H | 304 SS | 2-valve Manifolds | Body:304 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2RSS-BP8-RG8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male BSPP × 1/2 Female BSPP × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug | No Image |
| 2RSS-FL6-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 3/8" Tube Fitting, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with 1/4 NPT Plug. | No Image |
| 2RSS-FMS20-H | 316 SS | 2-valve Manifolds | The maximum working pressure is 6000psi. The operating temperature is -54℃ to 232℃. The inlet and outlet are M20×1.5 metric female thread; Horizontal valve installation | No Image |
| 2RSS-FMS20-H-G-P-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphite, Inlet&Outlet:M20×1.5 Female Metric Thread, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-FMS20-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:M20*1.5 Female Metric Thread, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-FMS20-NS8-H | 316 SS | 2-valve Manifolds | Remote two valve group, maximum working pressure 6000psi, operating temperature: -54℃ to 232℃; Imported M20×1.5 metric female thread; Outlet for 1/2NPT male thread, valve horizontal installation | No Image |
| 2RSS-FMS20-SFMS20-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, M20×1.5 Female Metric Thread× Siwivel M20×1.5 Female Metric Thread × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted。 | No Image |
| 2RSS-FNS4-A | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/4 Female NPT,PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | No Image |
| 2RSS-FNS4-A-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/4 Female NPT,PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern,FC-02 Cleaned | No Image |
| 2RSS-FNS4-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-FNS4-V | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2RSS-FNS4-V-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/4in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2RSS-FNS4-V-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, PTFE Packing, 6000psig(414bar), -54℃ to 232℃, Inlet&Outlet: 1/4 Female NPT, Vent: 1/4 Female NPT with plug, Valves Vertically Mounted, NACE MR0175 | No Image |
| 2RSS-FNS4-V-SI | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/4 Female NPT × 1/4 Female NPT, 1/4 Female NPT Vent, PTFE Packing, 6000 psig (414 bar), -65°F to 450°F (-54°C to 232°C), Valves Vertically Mounted,Inert Silicon Coated | No Image |
| 2RSS-FNS8-A | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | No Image |
| 2RSS-FNS8-A-G | 316 SS | 2-valve Manifolds | Body:316SS, Remote Mounting,MWP:6,000psig, Packing:Graphite, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, -65°F to 1200°F(-54°C to 649°C),Angle Pattern | No Image |
| 2RSS-FNS8-A-G-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphite, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting | No Image |
| 2RSS-FNS8-A-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, Test Port with Plug | No Image |
| 2RSS-FNS8-A-P-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting, FC-02 Cleaned | No Image |
| 2RSS-FNS8-A-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -54℃ to 232℃, Angle Pattern, NACE MR0175 | No Image |
| 2RSS-FNS8-A-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, Remote Mounting, T-bar Handles, NACE MR 0175 | No Image |
| 2RSS-FNS8-FMS20-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × M20×1.5 Female Thread(MS)× 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 2RSS-FNS8-FMS20-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in.(F)NPT, Outlet:M20*1.5 Female Metric Thread(for RP), Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-FNS8-FMS20-L | 316 SS | 2-valve Manifolds | The maximum working pressure is 6000psi. The operating temperature is -54℃ to 232℃. The inlet is 1/2NPT female thread, the outlet is M20×1.5 metric female thread; The valve is collinear distribution | No Image |
| 2RSS-FNS8-FMS20-L-P | 316 SS | 2-valve Manifolds | The maximum working pressure is 6000psi. The operating temperature is -54℃ to 232℃. The inlet is 1/2NPT female thread, the outlet is M20×1.5 metric female thread; Vent:1/4in. (F)NPT with Plug,,The valve is collinear distribution | No Image |
| 2RSS-FNS8-FMS20-V | 316 SS | 2-valve Manifolds | 2R Series, the MWP: is 6000psig, the working temperature is -54℃ to 232℃, the inlet is 1/2NPT female thread, one end is M20×1.5 female thread, valve surface is vertical distribution | No Image |
| 2RSS-FNS8-FRP8-H | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT x 1/2in.Female ISO Tapered Thread, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting | No Image |
| 2RSS-FNS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 2RSS-FNS8-H-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, FC-02 Cleaned | No Image |
| 2RSS-FNS8-H-G | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:Graphite, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-FNS8-H-G-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, GraphitePacking, 6000psig(414bar), -54℃ to 649℃, Valves Horizontally Mounted | No Image |
| 2RSS-FNS8-H-G-T | 316 SS | 2-valve Manifolds | Remote two valve group, maximum working pressure 6000psi, working temperature: -54 ℃ to 649 ℃; 1/2 "NPT female thread for inlet and outlet; valve installed horizontally; graphite packing seal with 1/4 NPT female thread hole+RB relief valve | No Image |
| 2RSS-FNS8-H-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -54℃ to 232℃, Valves Horizontally Mounted | No Image |
| 2RSS-FNS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug | No Image |
| 2RSS-FNS8-H-P-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Manifolds, Remote Mount, 1/2 FNPT × 1/2 FNPT × 1/4 FNPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug.Suitable for Marine environment | No Image |
| 2RSS-FNS8-H-P-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig,Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting, NACE MR0175 | No Image |
| 2RSS-FNS8-H-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, NACE MR0175-compliant | No Image |
| 2RSS-FNS8-MS20-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in.(F)NPT, Outlet:M20*1.5 Metric Thread(for RP), Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-FNS8-V-P-SWLK | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted,Test Port with Plug. | No Image |
| 2RSS-FNS8-V-S | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (F)NPT, Vent:1/4in. (F)NPT, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, Remote Mounting, NACE MR 0175 | No Image |
| 2RSS-FNS8-V-SI | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female NPT × 1/2 Female NPT, 1/4 Female NPT Vent, PTFE Packing, 6000 psig (414 bar), -65°F to 450°F (-54°C to 232°C), Valves Vertically Mounted,Inert Silicon Coated | No Image |
| 2RSS-FNS8-V-S-SWLK | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, 1/2 Female NPT × 1/2 Female NPT× 1/2 Female NPT,NACE MR0175 Compliant | No Image |
| 2RSS-FNS8-V-SWLK | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, 1/2 Female NPT × 1/2 Female NPT× 1/2 Female NPT | No Image |
| 2RSS-FRP8-H-P-HG | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds,1/2 Female BSPP (for RP) × 1/2 Female BSPP (for RP) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Test Port with Plug. | No Image |
| 2RSS-FRT8-H-M | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Female ISO Tapered Thread × 1/2 Female ISO Tapered Thread ×1/4 Female NPT, Valves Horizontally Mounted, stainless steel handle | No Image |
| 2RSS-ML12-V | 316 SS | 2-valve Manifolds | body 316 SS, 2-valve manifold, remote mount, inlet and outlet: 12mm metric tube fiiting, valves vertically mounted | No Image |
| 2RSS-MS14-FMS14-H-P | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:M14*1.5 Male Metric Thread, Outlet:M14*1.5 Female Metric Thread, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting | No Image |
| 2RSS-MS20-FMS20-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:M20*1.5 Male Metric Thread, Outlet:M20*1.5 Female Metric Thread, Vent:1/4in.(F)NPT, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-MS20-FMS20-H-F2 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:M20×1.5 Male Metric Thread, Outlet:M20×1.5 Female Metric Thread, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-MS20-FMS20-H-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Manifolds, Packing: PTFE, MWP: 6000psig, -54℃ to 232℃, Inlet: M20*1.5 Male Metric Thread, Outlet: M20*1.5 Female Metric Thread, Vent: 1/4 Female NPT, Valves Horizontally Mounted | No Image |
| 2RSS-MS20-FMS20-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:M20*1.5 Male Metric Thread, Outlet:M20*1.5 Female Metric Thread, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-MS20-SFMS20-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, M20×1.5 Male Metric Thread × M20×1.5 Rotatable Female Metric Thread × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 2RSS-MTB16×3-FMS20-H-G | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds | No Image |
| 2RSS-NS12-FMS20-H-P | 316 SS | 2-valve Manifolds | 2R Series, set pressure rangmaximum working pressure:41.4MPa,working temperature:-54~232℃,inlet：3/4 Male NPT,outlet:M20×1.5 Female | No Image |
| 2RSS-NS8-FNS8-H-G-P-Q26823 | 316 SS | 2-valve Manifolds | 316 SS, 2-valve Manifolds, Inlet: 1/2'' Male NPT, Outlet: 1/2'' Female NPT, Body Style: Valves Horizontally Mounted, Graphite Packing Sealing Material, Test Port and Plugs: 1/4'' Female NPT with Plug | No Image |
| 2RSS-NS8-FNS8-H-Q99309 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), Valves Horizontally Mounted,as per drawing | No Image |
| 2RSS-NS8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Male NPT × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 2RSS-NS8-H-G | 316 SS | 2-valve Manifolds | 316 SS, NG Series Needle Valves, Integral Bonnet, 1/2 Female ISO Tapered Thread, PTFE Packing, 6000psig(413bar), -65°F to 1200°F(-54°C to 649°C), 0.39" Orifice, Regulating Tip, Panel Mounting，Black alumina rod,Graphite filler | No Image |
| 2RSS-NS8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet&Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-NS8-H-P-ME | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:1/2in. (M)NPT, Vent:1/4in. (F)NPT, Cv:0.35, Al T-bar Handles, Config.:1-Block&1-Vent, Remote Mounting | No Image |
| 2RSS-NS8-MS20-H-P | 316 SS | 2-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (M)NPT, Outlet:M20 × 1.5 Male Metric Thread Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate & 1-Vent, In-line Mounting | No Image |
| 2RSS-NS8-SRG8-H-P-Q75394 | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male NPT × 1/2 Female Swivel ISO Parallel(SRG) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted, Vent with Plug. | No Image |
| 2RSS-RS8-FRP8-H-P | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, MWP:6000psig, Packing:PTFE, Inlet:1/2" BSPP(RS), Outlet:1/2" F BSPP(FRP), Vent:1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Isolate&1-Vent, In-line Mounting | No Image |
| 2RSS-RT8-FRT8-H | 316 SS | 2-valve Manifolds | 316 SS, 2R Series 2-valve Instrumentation Manifolds, Remote Mount, 1/2 Male ISO Tapered Thread(RT) × 1/2 Female ISO Tapered Thread(RT)× 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Horizontally Mounted | No Image |
| 3D6L-FNS8-L | 316L SS | 3-valve Manifolds | Body:316L SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange, Vent:/, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting | No Image |
| 3D6L-FNS8-V-P-M-ME | 316L SS | 3-valve Manifolds | 3D Series Direct Mount 3-valve Manifold,316 SS Body, Max. Working Pressure: 6, 000psig, Inlet/Process: 1/2" Female NPT, Outlet/Instrument: Flange, Test: 1/4" Female NPT with Plug, PTFE Packing | No Image |
| 3D6L-FRT8-A-M | 316L SS | 3-valve Manifolds | 3-valve Manifolds, Body: 316L SS, MWP: 6000psig, Packing: PTFE, Inlet: 1/2in. (F)BSPT, Outlet: Flange, Orifice:4mm, Cv: 0.35,316 SS Bolt. Al T-bar Handles, Config: 2-Isolate&1-Equalize, Direct Mounting | No Image |
| 3D6L-ML14-A-Q37401 | 316L SS | 3-valve Manifolds | 3D Series, working pressure 414bar, working temperature - 54-232 ℃, see the drawing for details | No Image |
| 3D6L-UMB14-A | 316L SS | 3-valve Manifolds | 316LSS, MWP:6000psig, Packing:PTFE, Inlet:14mm BW Bulge Nipple with Union Nut, Outlet:Flange, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | No Image |
| 3D6L-UMB14-A-F54 | 316L SS | 3-valve Manifolds | 316LSS, MWP:6000psig, Packing:PTFE, Inlet:14mm BW Bulge Nipple with Union Nut, Outlet:Flange, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | No Image |
| 3DD7-FNS8-L-P | Super Duplex | 3-valve Manifolds | Body:2507, MWP:6000psig, Packing:PTFE, Inlet:2Ports × 1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting | No Image |
| 3DS4-FNS8-C-P | 304 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange (Coplanar), Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | No Image |
| 3DSS-FNS4-A | 316 SS | 3-valve Manifolds | 316 SS, 3D Series 3-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/4 Female NPT × Flange(MSS SP-99), PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | No Image |
| 3DSS-FNS8-C-G-VML6-Q72504 | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:Graphite, Inlet:2Ports × 1/2in. (F)NPT,Outlet: Flang(Coplanar),Vent:1/4in (F)NPT with Fitting+Plug 6mm OD,Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:1-Equalize, Direct Mounting.As per drawing. | No Image |
| 3DSS-FNS8-C-P-VML6 | 316 SS | 3-valve Manifolds | 316 SS, MWP: 6000psig, Packing: PTFE,Inlet: 2Ports x 1/2in. (F)NPT, Outlet: Flange (Coplanar), Vent: 6mm OD with plug, Orifice: 4mm, Cv: 0.35, Al T-bar Handles, Config.: 2-Isolate, &1-Equalize, Direct | No Image |
| 3DSS-FNS8-L | 316 SS | 3-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:/, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting | No Image |
| 3DSS-FNS8-L-F2 | 316 SS | 3-valve Manifolds | 316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:/, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting | No Image |
| 3DSS-FNS8-L-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Plug, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting | No Image |
| 3DSS-FNS8-L-S | 316 SS | 3-valve Manifolds | 316SS, MWP:6,000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:/, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Direct Mounting，NACE | No Image |
| 3DSS-FNS8-L-T | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT With Relief Valves, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting | No Image |
| 3DSS-FNS8-L-T-S | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange, Vent:1/4in. (F)NPT with Bleed Valves, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent&1-Equalize, Direct Mounting, NACE MR 0175 | No Image |
| 3DSS-UMB14-A | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:14mm BW Bulge Nipple with Union Nut, Outlet:Flange, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Direct Mounting | No Image |
| 3RSS-UMB14×2-V-P | 316 SS | 3-valve Manifolds | 316 SS, MWP:6000psig, Packing:PTFE, Inlet:2Ports x 1/2in. (F)NPT, Outlet:2Ports x 1/2in. (F)NPT, Vent:1/4in.(F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate&1-Equalize, Remote Mounting | No Image |
| 3RSS-UMB16×3-V | 316 SS | 3-Valve Manifolds | 316 SS, 3R Series 3-valve Instrumentation Manifolds, Remote Mount, 14mm ×3mm Tube welding, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Valves Vertically Mounted | No Image |
| 5DSS-FL8-A | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2" Tube Fitting × Flange(MSS SP-99) × 1/4 Female NPT, PTFE Packing, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern | No Image |
| 5DSS-FNS8-AB | 316 SS | 5-valve Manifolds | 316 SS, 5D Series 5-valve Instrumentation Manifolds, Direct Mount(transmitter with coplanar mounting flange), 1/2 Female NPT × Flange(MSS SP-99) × 1/4 Female NPT, 6000psig(414bar), -65°F to 450°F(-54°C to 232°C), Angle Pattern, Double-equalize | No Image |
| 5DSS-FNS8-AB-1M | 316 SS | 5-valve Manifolds | 5D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20 × 3" bolt, Bolt 316 SS. | No Image |
| 5DSS-FNS8-AB-E-1M | 316 SS | 5-valve Manifolds | 5D Series,316SS, working pressure: 6000psig, working temperature:-54~232℃,inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, need be mounted with 7/16 -20 × 3" bolt | No Image |
| 5DSS-FNS8-AB-G-1M | 316 SS | 5-valve Manifolds | 5D Series, MWP:41.4MPa, working temperature:-54~232℃, inlet:1/2NPT Female,outlet:flange, Valves Vertically Mounted, 7/16 - 20 × 3" bolt, Bolt 316 SS. | No Image |
| 5DSS-FNS8-AB-P | 316 SS | 5-valve Manifolds | 316 SS, MWP:6000psig, Packing:Graphite, Inlet:2Ports x 1/2in. (F)NPT, Outlet:Flange(Wafer), Vent:2Ports x 1/4in. (F)NPT with Plug, Orifice:4mm, Cv:0.35, Al T-bar Handles, Config.:2-Isolate, 2-Vent,&1-Equalize, Direct Mounting | No Image |
| 5RSS-NFL8-V | 316 SS | 5-valve Manifolds | Body:316SS, MWP:6,000psig, Packing:graphite, Inlet:1/4in. (F)NPT, Outlet:1/2 , Vent:1/4in. (F)NPT+Plug, T-bar Handles, Config.:2-Isolate, 2-Vent & 1-Equalize, Vertically Mounted | No Image |
For more information on product models or customization services, please send your Inquiry
