Air Header and Distribution Manifold

CM Series Distribution Manifolds

Features
Working pressure up to 6000 pisg
Working temperature:
PTFE packing: -15 to 450°F (-26 to 232°C) Graphite packing: -15 to 1200°F (-26 to 649°C)
One-piece, integralbody, compact design
Linear instead of rotary movement of the rising, non-rotating stem minimizes packing abrasion and reduces the friction between the seat and the tip
Upper stem threads cold rolled and lower stem hardened for high strength and smooth operation
Fully back seat sealing at fully open position
Every distributionmanifold leak tested at factory with air or Nitrogen at rated working pressure



AH Series Air Headers

Features
Working pressure up to 1000 psig
Working temperature: 0 to 25018 to 121
Modular design for easy installation and maintenance
Standard module with 4 or 6 outlets available as an accessory and can be ordered separately°F (- °C)
Multiple choices of inlet and vent types, and in-line replacement available
Every air header leak tested at factory with air or Nitrogen at rated working pressure

Gauge Valve

Features
GV Series, GVH Series and GR Series
Working pressure up to: Stainless steel: GV, GR up to 6000 psig (414 bar)
GVH up to 10000 psig (690 bar) GV Series and GVH Series working temperature:PTFE packing: -65 F to 450 F (-54 C to 232 C)Graphite packing: -65 F to 1200 F (-54 C to 649 C)
GR Series working temperature:Acetal seat: -20 F to 250 F (-28 C to 121 C)PEEK seat: -20 F to 400 F (-28 C to 204 C



Non-rotating lower stem, ball tip and plug tip designs
Variety of materials for seat and packing
Safety back seating seals in fully open position
Rolled spindle operating threads
Lubricant for stem thread isolated from the media
Externally adjustable gland
Bonnet locking pin fitted as standard
Low torque operating T bar handle

Instrumentation Manifolds

Features
GV Series, GVH Series and GR Series
Working pressure up to: Stainless steel: GV, GR up to 6000 psig (414 bar)
GVH up to 10000 psig (690 bar) GV Series and GVH Series working temperature:PTFE packing: -65 F to 450 F (-54 C to 232 C)Graphite packing: -65 F to 1200 F (-54 C to 649 C)
GR Series working temperature:Acetal seat: -20 F to 250 F (-28 C to 121 C)PEEK seat: -20 F to 400 F (-28 C to 204 C





Non-rotating lower stem, ball tip and plug tip designs
Variety of materials for seat and packing
Safety back seating seals in fully open position
Rolled spindle operating threads
Lubricant for stem thread isolated from the media
Externally adjustable gland
Bonnet locking pin fitted as standard
Low torque operating T bar handle
